DS-E3

DS-E3

"The game changer"

DS-E3

Truly beyond price.
The DS-E3 is a revolutionary technology in historic record reproduction.

Ikuo Kakuta, Audio Critic

Details

Cartridge

Uses a third-generation optical cartridge mechanism

The DS-E3 uses a third-generation optical cartridge mechanism, the same design as our other products.
The DS-E3 achieves an overwhelmingly low price while inheriting the merits of the third-generation mechanism, such as higher output due to independent LED and PD, improved channel separation, and the use of a beryllium light shielding plate.

Aluminum cantilever with elliptical needle

The cantilever is made of aluminum and the needle tip is a solid elliptical needle. While adopting the third-generation optical cartridge mechanism, the channel separation is set 1db lower to improve mass production efficiency.

Equalizer

New Amplification and Power Supply Circuits

In the DS-E3 equalizer, the amplification circuit has been made symmetrical, and the voltage supplied to the cartridge has been stabilized to achieve a clearer and faster sound.

Miniaturization is achieved by using an operational amplifier

The DS-E3 equalizer uses an operational amplifier as the amplifying element to minimize the signal path, thereby greatly reducing the number of components and achieving a smaller size. As a result, the DS-E3 equalizer is about 1/3 the size of the DS003 equalizer.

DS-E3 Optical Cartridge
Signal output
Photo-electric Conversion
Channel separation
26db more (1kHz)
Weight
7.7g
Output signal level
70mV more
Canti-lever
Alminum
Body material
Alminum
Needle pressure
2.0g~2.2g(2.1g is recommended)
Stylus
Elliptical Needle
DS-E3 Equalizer for Optical Cartridge
Output voltage
500mV(1kHz)
Output impedance
120Ω
Pre amp input impedance
More than 10kΩ
Input terminal
RCA terminal
Output terminal
RCA terminal (Switch two outputs with switch)
Size
W26cm×H6.9cm×D19.5cm
Weight
1.86kg
